一：默认交换机

平均分配消息到custom, routing_key会将交换机的消息路由到指定的队列中

• 消费者

  #!/usr/bin/env python
  import pika

  connection = pika.BlockingConnection(pika.ConnectionParameters(host='localhost'))
  channel = connection.channel()

  channel.queue_declare(queue='hello')

  def callback(ch, method, properties, body):
      print(" [x] Received %r" % body)

  channel.basic_consume('hello', callback, False)

  print(' [*] Waiting for messages. To exit press CTRL+C')
  channel.start_consuming()

• 生产者

  import pika
  import random

  # 新建连接 rabbitmq安装在本地则hostname为localhost
  hostname = 'localhost'
  parameters = pika.ConnectionParameters(hostname)
  connection = pika.BlockingConnection(parameters)

  # 创建通道
  channel = connection.channel()
  # 声明一个队列 生产者和消费者都要声明一个相同的队列 用来防止万一某一方挂了 另一方还能正常运行
  channel.queue_declare(queue='hello')

  number = random.randint(1, 100)
  body = f'Hello World:{number}'

  # 交换机; 队列名  写明将消息发往哪个队列 消息内容
  channel.basic_publish(exchange='', routing_key='hello', body=body)
  print(f"[x] Sent {body}")
  connection.close()

二： 公平调度即当前消费者正在处理消息 管道(channel)将队列的消息指派给其他消费者

• 消费者

  #!/usr/bin/env python
  import pika
  import time

  connection = pika.BlockingConnection(pika.ConnectionParameters(
          host='localhost'))
  channel = connection.channel()

  channel.queue_declare(queue='task_queue', durable=True)
  print (' [*] Waiting for messages. To exit press CTRL+C')

  def callback(ch, method, properties, body):
      print (" [x] Received %r" % (body,))
      time.sleep( body.decode('utf-8').count('.') )
      print (" [x] Done")
      # 消息重新入队列 当这个消费者挂掉之后 消息重新入队列  发送给其他消费者
      ch.basic_ack(delivery_tag = method.delivery_tag)

  # 公平调度
  channel.basic_qos(prefetch_count=1)
  channel.basic_consume('task_queue',callback)

  channel.start_consuming()

• 生产者

  #!/usr/bin/env python
  import pika
  import sys

  connection = pika.BlockingConnection(pika.ConnectionParameters(
          host='localhost'))
  channel = connection.channel()

  # 队列持久化
  channel.queue_declare(queue='task_queue', durable=True)

  message = ' '.join(sys.argv[1:]) or "Hello World!"
  # delivery_mode 消息持久化
  channel.basic_publish(exchange='',
                        routing_key='task_queue',
                        body=message,
                        properties=pika.BasicProperties(
                           delivery_mode = 2, # make message persistent
                        ))
  print (" [x] Sent %r" % (message,))
  connection.close()

三：扇形交互机

将消息发送到它知道的所有的队列(忽略routing_key路由键的值)，将消息发送到与交互机绑定的队列中

• 消费者

  import pika

  connection = pika.BlockingConnection(pika.ConnectionParameters(
          host='localhost'))
  channel = connection.channel()

  channel.exchange_declare(exchange='logs', exchange_type='fanout')
  # 当与消费者（consumer）断开连接的时候，这个队列应当被立即删除
  result = channel.queue_declare(queue='' ,exclusive=True)
  queue_name = result.method.queue
  #n 队列绑定交换机
  channel.queue_bind(exchange='logs', queue=queue_name)

  print('[*] Waiting for logs To exit press CTRL+C')

  def callback(ch, method, properties, body):
      print('[x] %r'%(body,))

  channel.basic_consume(queue=queue_name, on_message_callback=callback, auto_ack=True)
  channel.start_consuming()

• 生产者

  import pika
  import sys

  connection = pika.BlockingConnection(pika.ConnectionParameters(host='localhost'))
  channel = connection.channel()

  # 定义交换机: 扇形交换机
  channel.exchange_declare(exchange='logs', exchange_type='fanout')
  message = ' '.join(sys.argv[1:]) or "info: Hello World!"
  channel.basic_publish(exchange='logs',
                        routing_key='',
                        body=message)

  print (" [x] Sent %r" % (message,))
  connection.close()

四：直连交换机

直连交互机可以指绑定一个队列 也可以通过routing_key绑定多个队列

比如：日志记录 error日志写入磁盘 而error, warning, info 时，都打印在输出台

• 消费者

  #!/usr/bin/env python
  import pika, sys, os

  def main():
      connection = pika.BlockingConnection(
      pika.ConnectionParameters(host='localhost'))
      channel = connection.channel()

      channel.exchange_declare(exchange='direct_logs', exchange_type='direct')

      result = channel.queue_declare(queue='', exclusive=True)
      queue_name = result.method.queue
      # 获取运行py文件额外的参数
      severities = sys.argv[1:]
      if not severities:
          sys.stderr.write("Usage: %s [info] [warning] [error]\n" % sys.argv[0])
          sys.exit(1)

      for severity in severities:
          channel.queue_bind(
              exchange='direct_logs', queue=queue_name, routing_key=severity)

      print(' [*] Waiting for logs. To exit press CTRL+C')


      def callback(ch, method, properties, body):
          print(" [x] %r:%r" % (method.routing_key, body.decode()))


      channel.basic_consume(
          queue=queue_name, on_message_callback=callback, auto_ack=True)

      channel.start_consuming()


  if __name__ == '__main__':
      try:
          main()
      except KeyboardInterrupt:
          print('Interrupted')
          try:
              sys.exit(0)
          except SystemExit:
              os._exit(0)

• 生产者

  #!/usr/bin/env python
  import pika
  import sys

  connection = pika.BlockingConnection(
      pika.ConnectionParameters(host='localhost'))
  channel = connection.channel()

  channel.exchange_declare(exchange='direct_logs', exchange_type='direct')

  severity = sys.argv[1] if len(sys.argv) > 2 else 'info'
  message = ' '.join(sys.argv[2:]) or 'Hello World!'
  channel.basic_publish(
      exchange='direct_logs', routing_key=severity, body=message)
  print(" [x] Sent %r:%r" % (severity, message))
  connection.close()

如果你希望只是保存warning和error级别的日志到磁盘，只需要打开控制台并输入：

$ python receive_logs_direct.py warning error > logs_from_rabbit.log

如果你希望所有的日志信息都输出到屏幕中，打开一个新的终端，然后输入：

$ python receive_logs_direct.py info warning error
 [*] Waiting for logs. To exit press CTRL+C

如果要触发一个error级别的日志，只需要输入：

$ python emit_log_direct.py error "Run. Run. Or it will explode."
 [x] Sent 'error':'Run. Run. Or it will explode.'
